Approved / Certified by:
fire rating: 27Â A 233 BÂ 40Â F
- 6 L. foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to UNI EN 3-7 (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU.
 -Quality Product certification guaranteed by Bureau Veritas Italia.
-Â Suitable for use on fire involving electrical voltages up to 35. 000 V, at a distance of 1 mt.
Chracteristics :Â
- Cylinder:Alloy steel, deep drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing agent:Â Water foamÂ
- Propellant: Dehumidified air or N2.
- Valve:Â M. 30x1.5, brass body, levers with red painting Ral 3000.
- Use: A B F fire rating (solid materials, flammable liquids, cooking oils).
- Bracket:Â Wall-mounted for valve, in standard equipment.
- Clip detail :
Â
Technical specifications:
- Fire rating: 27Â A 233Â B 40 F
-Â Extinguishing agent:Â EWAB15 foam (2 % SC 6 + 10 % Inilam AX + 88 % Water)
- Propellant: Dehumidified air or N2, 15 Bar A 20°C
- Temperature range: +0°C /+60°C
-Â Nominal charge: 6 L
-Â Full weight: ~ 9,4Â Kg
-Â Dimension: Height (base-valve):Â 540 mm -Â Diameter: 160Â mm
- Discharge time:Â 43Â sec.
- Valve tigtening torque: Minimum:Â 45 Nm, Maximum: 68 Nm
- Cylinder pressure test: PT 27 Bar
- Cylinder volume: 7,5Â L.
- Safety valve: Set between 20 and 26 Bar
- Cylinder material:Â Alloy steel
- External/Internal treatment:Â Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour/ Internal plastic lining
