Approved / Certified:

Fire Rating: 13Â A 113Â B C

- 3 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7,
approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment
PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Features:
- Cylinder: Alloy steel, deep drawing, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: ABC Powder - MAP 20 %.
- Propellant: Dehumidified air or N2.
- Valve: M. 30x1.5, lightweight aluminum alloy AA6061 body, levers with red painting Ral 3000.
- Use: A B C fire rating (solid materials, flammable liquids, flammable gas).
Â
Technical Specifications:
- Fire Rating: 13 A 113Â B C
- Extinguishing Agent: EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: -30°C / +60°C
- Nominal Charge:Â 3Â Kg
- Full Weight: ~ 5,3Â Kg
- Dimensions: Height 470 mm, Diameter 130Â mm
- Discharge Time: 15Â sec.
- Max Valve Tightening: Minimum 35 Nm, Maximum 55 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 4,3Â L.
- Safety Valve: Set between 22 and 27 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
