Portable Fire Extinguisher 9 L Foam - model 32093-610 - GW9AI

Portable Fire Extinguisher 9 L Foam - model 32093-610 - GW9AI

32093-610
Foam 9 kg



Fluorine Free

9 L foam fire extinguisher, auxiliary pressure, temperature range from +5°C to +60°C, manufactured in accordance
to UNI EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according
at productions checks as agreed with EN 3-10.



Fire Class AB
Portable Fire Extinguisher 9 L Foam - model 32093-610 - GW9AI
Portable Fire Extinguisher 9 L Foam - model 32093-610 - GW9AI

Portable Fire Extinguisher 9 L Foam - model 32093-610 - GW9AI

Approved/ Certified Fire Extinguisher:

Fire Rating:   34 A 183 B

9 L foam fire extinguisher, auxiliary pressure, temperature range from +5°C to +60°C, manufactured in accordance
to UNI EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according
at productions checks as agreed with EN 3-10. Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.

Characteristics:

  • CYLINDER In high-strength alloy steel, with clip, deep drawing, external powder painting Red Ral 3000.
  • EXTINGUISHING AGENT Water + cartridge with foaming additive, fluorine free.
  • PROPELLANT Auxiliary pressure. Fire extinguisher pressurized at moment of use with 80g CO2 cartridge.
  • VALVE. 74x2, aluminum body, levers with green painting Ral 6018.
  • USE A B fire rating (solid materials, flammable liquids).

Technical Specifications:

  • FIRE RATING: 34 A 183 B
  • EXTINGUISHING AGENT: Water (8,91 L) + Green Wave Premix (90 ml cartridge) (* Hyper-filtered water with an osmosis process)
  • PROPELLANT: Cartridge with 80 g CO2
  • TEMPERATURE RANGE:  +5°C / +60°C
  • NOMINAL CHARGE: 9 Liters
  • FULL WEIGHT: ~ 14,95 Kg
  • DIMENSIONS: Height (base - valve) 620 +/- 5 mm (with bottom) Diameter (cylinder) 182 +/- 2 mm

Technical Specifications:

  • FIRE RATING: 34 A 183 B
  • EXTINGUISHING AGENT: Water (8,91 L) + Green Wave Premix (90 ml cartridge) (* Hyper-filtered water with an osmosis process)
  • PROPELLANT: Cartridge with 80 g CO2
  • TEMPERATURE RANGE:  +5°C / +60°C
  • NOMINAL CHARGE: 9 Liters
  • FULL WEIGHT: ~ 14,95 Kg
  • DIMENSIONS: Height (base - valve) 620 +/- 5 mm (with bottom) Diameter (cylinder) 182 +/- 2 mm

Data Sheets, Manual and Certificates:

Manual and Data Sheet
Technical Manual
PED Certificate 2014/68/UE
