Approved / Certified Fire Extinguisher:

Fire Rating: 27 A 144 B

6 L foam fire extinguisher, auxiliary pressure, temperature range from +5°C to +60°C, manufactured in
accordance to UNI EN 3-7, approved Marine Equipment Directive MED 2014/90/EU, certified according to
the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as
agreed with EN 3-10. Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.
Characteristics:
- CYLINDER In high-strength alloy steel, with clip, deep drawing, external powder painting Red Ral 3000.
- EXTINGUISHING AGENT Water + cartridge with foaming additive, fluorine free.
- PROPELLANT Auxiliary pressure. Fire extinguisher pressurized at moment of use with 60g CO2 cartridge.
- VALVEM. 74x2, aluminum body, levers with green painting Ral 6018.
- USE A B fire rating (solid materials, flammable liquids).
Technical Specifications:
- FIRE RATING: 27 A 144 B
- EXTINGUISHING AGENT: Water (5,94 L) + Green Wave Premix (60 ml cartridge) (* Hyper-filtered water with an osmosis process)
- PROPELLANT: Cartridge with 60 g CO2
- TEMPERATURE RANGE: +5°C / +60°C
- NOMINAL CHARGE: 6 Liters
- FULL WEIGHT: ~ 10,65 Kg
- DIMENSIONS: Height (base - valve) 555 +/- 5 mm (with bottom) Diameter (cylinder) 162 +/- 2 mm
