Foam Portable fire extinguisher L 6 UNI En 3-7 - Model: 32063-1
Foam Portable fire extinguisher L 6 UNI En 3-7 - Model: 32063-1

Foam Portable fire extinguisher L 6 UNI En 3-7 - Model: 32063-1

Data Sheet
PED Certificate 2014/68/UE

6 L. foam fire extinguisher, pressurized at moment of use, temperature range from +5°C to +60°C, manufactured in accordance to EN 3-7:2008, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.

Foam Portable fire extinguisher L 6 UNI En 3-7 - Model: 32063-1

6 L Foam Portable fire extinguisher - PED En 3-7 - Model: 32063-1





APPROVED/CERTIFIED:

Certified fire extinguisher



FIRE CLASS : 34 A - 233 B

Foam Portable fire extinguisher L 6 UNI En 3-7 - Model: 32063-1



9 L. foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU. Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 35.000 V, at a distance of 1 mt.



Features:

- Cylinder: Alloy steel, 3 pieces drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.

- Extinguishing Agent: water foam.
- Propellant: Fire extinguisher pressurized at moment of use with gr.55 CO2 cartridge.
- Valve: M. 74x2, lightweight aluminum alloy, activation with percussion method..
- Use: A B fire rating (solid materials, flammable liquids).
- Bracket: WWall-mounted bracket for fire extinguisher with clip, red painting, in standard equipment.

Technical Specifications :

  • Fire Rating: 34 A 233 B
  • Extinguishing Agent: EWAB15 foam
  • Propellant: Internal cartridge with gr. 55 CO2
  • Temperature Range: 5°C +60°C
  • Nominal Charge: 6 L
  • Full Weight: ~ 11,1 Kg
  • Dimensions: Height  520 mm, Diameter 160 mm
  • Discharge Time: 35 sec.
  • Valve Tightening Torque: Minimum 40 Nm, Maximum 60 Nm
  • Cylinder Pressure Test: PT 27 bar
  • Cylinder Volume: 7,1 L.
  • Safety Valve: Set 24 +/- 2 bar
  • Cylinder Material: Alloy steel
  • External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour / Internal plastic lining

Technical Specifications :

  • Fire Rating: 34 A 233 B
  • Extinguishing Agent: EWAB15 foam
  • Propellant: Internal cartridge with gr. 55 CO2
  • Temperature Range: 5°C +60°C
  • Nominal Charge: 6 L
  • Full Weight: ~ 11,1 Kg
  • Dimensions: Height  520 mm, Diameter 160 mm
  • Discharge Time: 35 sec.
  • Valve Tightening Torque: Minimum 40 Nm, Maximum 60 Nm
  • Cylinder Pressure Test: PT 27 bar
  • Cylinder Volume: 7,1 L.
  • Safety Valve: Set 24 +/- 2 bar
  • Cylinder Material: Alloy steel
  • External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour / Internal plastic lining
