APPROVED/CERTIFIED FIRE EXTINGUISHER:
Â
FIRE CLASS : 34Â A - 233Â B - 75Â F
Â
Characteristics:
- CYLINDER Alloy steel, deep drawing, epoxypolyestere powder painting, Red Ral 3000.
- EXTINGUISHING AGENT Water foam.
- PROPELLANT Dehumidified air or N2 .
- VALVE M. 30x1.5, brass body, levers with red painting Ral 3000.
- Â USE A B F fire rating (solid materials, flammable liquids, cooking oils).
Suitable for use on Polar Solvents
Â
Technical specifications:
- Fire rating: 34 A 233 B 75 F
-Â Extingushing agent: EW-30 foam (100 % Premix MG6 -30)
- PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
- Temperature range : -30°C / +60°C
- Nominal charge : 6Â L
- Full weight: ~ 10,4Â kg
-Â Dimensions:Â Height(base-valve) 540 mm - Diameter 160 mm
- Discharge time: 35,5 sec.
- Valve tightening torque: Minimum 45 Nm, Maximum 68 Nm
- Cylinder pressure test: PT 27 Bar
- Cylinder volume:7,5 L
- Safety valve : Set between 20 and 26 bar
- Cylinder material: Alloy steel
- External/INternal treatment:Â Sandblast and epoxypolyestere poweder painting, Red Ral 3000 colour
