​APPROVED/CERTIFIED:
Â
FIRE RATING: 55Â A 233 B CÂ
- 6 Kg powder fire extinguisher built with low magnetic conductivity components, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7, (D.M. 7.1.2005), certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.
Characteristics:
- CYLINDERÂ Stainless steel, 3 pieces drawing, external powder painting Red Ral 3000.
- EXTINGUISHING AGENTÂ ABC Powder - MAP 20 %
- PROPELLANTÂ Dehumidified air or Nitrogen (N2).
- VALVEÂ Not magnetic M. 30x1.5, brass body, inox levers, specific for low magnetic conductivity fire extinguisher.
- USEÂ A B C fire rating (solid materials, flammable liquids, flammable gas).
NOTE:Â Fire extinguisher built with low magnetic conductivity components.
​
TECHNICAL SPECIFICATIONS:
- FIRE RATING: 55 A 233 B C
- EXTINGUISHING AGENT: ABC powder - MAP 20 % (ABC Favorit Tertia - Rühl)
- PROPELLANT: Dehumidified air or Nitrogen (N2), 15 bar at 20°C
- TEMPERATURE RANGE: -30°C / +60°C
-Â NOMINAL CHARGE: 6 Kg
-Â FULL WEIGHT: ~ 8,8 Kg
-Â DIMENSIONSÂ Height (base - valve) 530 +/- 5 mm - Diameter (cylinder) 160 +/- 2 mm
-Â DISCHARGE TIME: ~ 18,7 seconds
-Â VALVE TIGHTENING TORQUE: Minimum 45 Nm, Maximum 68 Nm
-Â CYLINDER PRESSURE TEST: PT 27 Bar
-Â CYLINDER VOLUME: 7,8 L.
-Â SAFETY VALVE: Set between 20 and 24 bar
-Â CYLINDER MATERIAL: Stainless steel
-Â TREATMENT: Outside: Sandblast and powder painting, Ral 3000
