50 Kg powder wheeled fire extinguisher, auxiliary pressure, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 1866-1 (D.M. 6.3.92), certified according to the directive for pressure equipment PED 2014/68/EU.
- 50 Kg powder wheeled fire extinguisher, auxiliary pressure, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 1866-1 (D.M. 6.3.92), certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristics:
- Cylinder: In high-strength alloy steel, external powder painting Red Ral 3000.
- Extinguishing Agent: ABC Powder - MAP 20 %.
- Propellant : Auxiliary pressure. Fire extinguisher pressurized at moment of use with CO2 external cylinder, complete of protection
for valve .
- CAP: Brass 2''.
- Use: A B C fire rating (solid materials, flammable liquids,flammable gas).
- Bracket: Chassis on wheels, welded at the cylinder, red painting Ral 3000.
- Fire Rating: A IV B C
- Extinguishing Agent: ABC Powder - MAP 20 % (ABC Favorit Tertia - Rühl)
- Propellant: 1,2 Kg di CO2
- Temperature Range: -30°C /+60°C
- Nominal Charge: 50 Kg
- Full Weight: ~ 85 kg
- Dimensions : Height 1100 +/-10 mm ; Width 490 +/-10 mm - Depth 560 +/-10 mm
- Discharge Time: ~ 59,2 sec.
- Cap Tightening Torque: Minimum 60 Nm, Maximum 70 Nm
- Cylinder Pressure Test: PT 30 bar
- Cylinder Volume : 62 L.
- Safety Device: Set between 21 and 26 bar
- Cylinder Material: Alloy steel
- Treatment: Outside : Sandblast and powder painting Ral 3000
