Characteristics:
- Cylinder: Alluminium alloy AA6061, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: Carbon Dioxide 99,99%
- Valve: CPF M 25X2, brass body, levers with red painting RAL3000.
- Use: B fire rating (flammable liquids).
- Bracket: Wall-mounted for valve in standard equipment.
- Fire Rating: 89 B
- Extinguishing Agent: Co2 99,99%
- Temperature Range: -30°C +60°C
- Nominal Charge: 5 Kg
- Full Weight: ~ 12,1 Kg
- Dimensions: Height 670 mm, Diameter 152 mm
- Discharge Time: 11,5 sec.
- Valve Tightening Torque : Minimum 95 Nm, Maximum 130 Nm
- Cylinder Pressure Test: PT 212 bar
- Cylinder Volume: 7,5 L.
- Safety Valve: Set 195 +15/-23 bar
- Cylinder Material: Alluminium alloy AA6061
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
