3 L. Foam Fire Extinguisher- Code 22031-1 13A 113B 40F- Stainless steel AISI 304- UNI EN 3-7

Code

22031-1

Data Sheet

Ministerial approval

PED Certificate 2014/68/UE

MED Certificate Module B

MED Certificate Module D

3 L. foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to UNI EN 3-7 (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10

Product Details
Technical Specifications

3 L. Foam Fire Extinguisher- Code 22031-1 13A 113B 40F- Stainless steel AISI 304- UNI EN 3-7

FIRE CLASS : 13A - 113B -40F

Characteristics:

• CYLINDER Stainless steel AISI 304, 3 pieces drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.
• EXTINGUISHING AGENT Water foam.
• PROPELLANT Dehumidified air or N2 .
• VALVE M. 58x2, lightweight aluminum alloy AA6061 body, with external check valve, levers with black painting.
• USE A B F fire rating (solid materials, flammable liquids, cooking oils).
• BRACKET Wall-mounted for valve, in standard equipment

Technical Specifications:

FIRE RATING 13 A 113 B 40 F
EXTINGUISHING AGENT EWAB15 foam (2 % SC 6 + 12 % Inilam AX + 86 % Water)
PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
TEMPERATURE RANGE 0°C / +60°C
NOMINAL CHARGE 3 L.
FULL WEIGHT ~ 5,7 Kg
DIMENSIONS Height 445 mm Diameter 130 mm
DISCHARGE TIME 19 sec.
VALVE TIGHTENING TORQUE Minimum 40 Nm, Maximum 60 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 3,9 L.
SAFETY VALVE Set between 22 and 27 bar
CYLINDER MATERIAL Stainless steel AISI 304
EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour

Technical Specifications:

FIRE RATING 13 A 113 B 40 F
EXTINGUISHING AGENT EWAB15 foam (2 % SC 6 + 12 % Inilam AX + 86 % Water)
PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
TEMPERATURE RANGE 0°C / +60°C
NOMINAL CHARGE 3 L.
FULL WEIGHT ~ 5,7 Kg
DIMENSIONS Height 445 mm Diameter 130 mm
DISCHARGE TIME 19 sec.
VALVE TIGHTENING TORQUE Minimum 40 Nm, Maximum 60 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 3,9 L.
SAFETY VALVE Set between 22 and 27 bar
CYLINDER MATERIAL Stainless steel AISI 304
EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
