12 Kg Powder Fire Extinguisher- Code 21125-2- 55A 233BC-UNI EN 3-7

Data Sheet

Ministerial approval

PED Certificate 2014/68/UE

MED Certificate Module B

MED Certificate Module D

12 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.

Product Details
Technical Specifications

12 Kg Powder Fire Extinguisher- Code 21125-2- 55A 233BC-UNI EN 3-7

FIRE CLASS: 55A - 233BC

-12 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.

-Quality Product certification guaranteed by Bureau Veritas Italia.

-Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.

Characteristics:

• CYLINDER Alloy steel, 3 pieces drawing, epoxypolyestere powder painting, Red Ral 3000.
• EXTINGUISHING AGENT ABC Powder - MAP 20 %.
• PROPELLANT Dehumidified air or N2 .
• VALVE M. 30x1.5, brass body, levers with red painting Ral 3000.
• USE A B C fire rating (solid materials, flammable liquids, flammable gas).
• BRACKET Wall-mounted for valve, in standard equipment

Technical Specifications:

FIRE RATING 55 A 233 B C
EXTINGUISHING AGENT EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
TEMPERATURE RANGE -30°C / +60°C
NOMINAL CHARGE 12 Kg
FULL WEIGHT ~ 17,6 Kg
DIMENSIONS Height 610 mm Diameter 190 mm
DISCHARGE TIME 29,5 sec.
VALVE TIGHTENING TORQUE Minimum 45 Nm, Maximum 68 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 12,5 L.
SAFETY VALVE Set between 20 and 26 bar
CYLINDER MATERIAL Alloy steel
EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour

Technical Specifications:

FIRE RATING 55 A 233 B C
EXTINGUISHING AGENT EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
TEMPERATURE RANGE -30°C / +60°C
NOMINAL CHARGE 12 Kg
FULL WEIGHT ~ 17,6 Kg
DIMENSIONS Height 610 mm Diameter 190 mm
DISCHARGE TIME 29,5 sec.
VALVE TIGHTENING TORQUE Minimum 45 Nm, Maximum 68 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 12,5 L.
SAFETY VALVE Set between 20 and 26 bar
CYLINDER MATERIAL Alloy steel
EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
