100 kg Powder Wheeled Fire Extinguisher - EN 1866-1- A IV B C - Model 18118-52

18118-52
Powder 100 kg

100 Kg powder wheeled fire extinguisher, auxiliary pressure, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 1866-1, approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU.

Fire Class ABC
100 kg Powder Wheeled Fire Extinguisher - EN 1866-1- A IV B C - Model 18118-52
100 kg Powder Wheeled Fire Extinguisher - EN 1866-1- A IV B C - Model 18118-52

100 kg Powder Wheeled Fire Extinguisher - EN 1866-1- A IV B C - Model 18118-52

APPROVED/CERTIFIED FIRE EXTINGUISHER:

Certified

FIRE RATING : A  IV B C

classe di fuoco a b c

Characteristics :

  •  CYLINDER In high-strength alloy steel, external powder painting Red Ral 3000.
  •  EXTINGUISHING AGENT ABC Powder - MAP 40 %.
  •  PROPELLANT Auxiliary pressure. Fire extinguisher pressurized at moment of use with CO2 external cylinder, complete of protection for valve) .
  •  CAP Brass 2”.
  •  USE A B C fire rating (solid materials, flammable liquids, flammable gas).
  •  BRACKET Chassis on wheels, welded at the cylinder, red painting RAL3000.

Technical specifications :

  • FIRE RATING A IV B C
  • EXTINGUISHING AGENT ABC Powder Emme Powder 40 - MAP 40 % (QFIRE 40 - Quimica 21, S.L.)
  • PROPELLANT 2,5 Kg CO2
  • TEMPERATURE RANGE -30°C / +60°C
  • NOMINAL CHARGE 100 Kg
  • FULL WEIGHT ~ 175 Kg
  • DIMENSIONS Height 1265 +/-10 mm ; Width 560 +/-10 mm - Depth 540 +/-10 mm
  • DISCHARGE TIME ~ 61,7 seconds
  • CAP TIGHTENING TORQUE Minimum 60 Nm, Maximum 70 Nm
  • CYLINDER PRESSURE TEST PT 30 bar
  • CYLINDER VOLUME 102 L.
  • SAFETY VALVE Set between 21 and 26 bar
  • CYLINDER MATERIAL Alloy steel
  • TREATMENT Outside : Sandblast and powder painting Ral 3000

Technical specifications :

  • FIRE RATING A IV B C
  • EXTINGUISHING AGENT ABC Powder Emme Powder 40 - MAP 40 % (QFIRE 40 - Quimica 21, S.L.)
  • PROPELLANT 2,5 Kg CO2
  • TEMPERATURE RANGE -30°C / +60°C
  • NOMINAL CHARGE 100 Kg
  • FULL WEIGHT ~ 175 Kg
  • DIMENSIONS Height 1265 +/-10 mm ; Width 560 +/-10 mm - Depth 540 +/-10 mm
  • DISCHARGE TIME ~ 61,7 seconds
  • CAP TIGHTENING TORQUE Minimum 60 Nm, Maximum 70 Nm
  • CYLINDER PRESSURE TEST PT 30 bar
  • CYLINDER VOLUME 102 L.
  • SAFETY VALVE Set between 21 and 26 bar
  • CYLINDER MATERIAL Alloy steel
  • TREATMENT Outside : Sandblast and powder painting Ral 3000

Data Sheets, Manual and Certificates:

Manual and Data Sheet
Technical Manual
PED Certificate 2014/68/UE
MED Certificate Module B
MED Certificate Module D
