Information Valid for PED model as for MED one:
Approved / Certified:
Fire Rating: 34Â A 233Â B C
- 6 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7
(D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for
pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Features:
- Cylinder: Alloy steel, deep drawing, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: ABC Powder - MAP 20 %.
- Propellant: Dehumidified air or N2.
- Valve: Brass M 30X1.5, levers with red painting RAL3000.
- Use: A B C fire rating (solid materials, flammable liquids, flammable gas).
Â
Technical Specifications:
- Fire Rating: 34 A 233Â B C
- Extinguishing Agent: EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: -30°C / +60°C
- Nominal Charge: 6 Kg
- Full Weight: ~ 9,4Â Kg
- Dimensions: Height(base-valve)Â 540mm - Diameter 160Â mm
- Discharge Time:Â 23Â sec.
- VALVE TIGHTENING TORQUE:Â Minimum 45 Nm, Maximum 68 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 7,8Â L.
- Safety Valve: Set between 20 and 26 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
