2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-7
2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-7

2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-7

Code
23058-5
Data Sheet

2Kg Co2 fire extinguisher, temperature range from -20°C to +60°C, manufactured in accordance to EN 3-7:2008, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.

2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-7

APPROVED/CERTIFIED:

2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-1



FIRE CLASS : 34 B

2 Kg Co2 Fire Extinguisher EN3/7 PED 2014/68/EU - Model 23020-1





2Kg Co2 fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7:2008, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.
Quality Product certification guaranteed by Bureau Veritas Italia. Suitable for use on fire involving voltages of up to 1000 volts.

• CYLINDER: Aluminum alloy AA6061, epoxypolyestere powder painting, Red Ral 3000..
• EXTINGUISHING AGEN:Carbon Dioxide 99,99%
• VALVE: CPF brass M 25X2, brass body, levers with black painting.
• USE: B fire rating (flammable liquids)
• BRACKET: Wall-mounted for valve in standard equipment.

  • FIRE RATING: 34 B
  • EXTINGUISHING AGENT: Co2 99,99%
  • TEMPERATURE RANGE: -20°C +60°C
  • NOMINAL CHARGE: 2 Kg
  • FULL WEIGHT: ~ 5,1 Kg
  • DIMENSIONS: Height 520 mm Diameter 117 mm
  • DISCHARGE TIME: 7 sec.
  • VALVE TIGHTENING TORQUE: Minimum 95 Nm, Maximum 130 Nm
  • CYLINDER PRESSURE TEST PT: 212 bar
  • CYLINDER VOLUME: 3 L.
  • SAFETY VALVE: Set 195 +15/-23 bar
  • CYLINDER MATERIAL: Alluminium alloy AA6061
  • EXTERNAL/INTERNAL TREATMENT: Sandblast and epoxypolyestere poweder painting, Red Ral 3000 colour
  • FIRE RATING: 34 B
  • EXTINGUISHING AGENT: Co2 99,99%
  • TEMPERATURE RANGE: -20°C +60°C
  • NOMINAL CHARGE: 2 Kg
  • FULL WEIGHT: ~ 5,1 Kg
  • DIMENSIONS: Height 520 mm Diameter 117 mm
  • DISCHARGE TIME: 7 sec.
  • VALVE TIGHTENING TORQUE: Minimum 95 Nm, Maximum 130 Nm
  • CYLINDER PRESSURE TEST PT: 212 bar
  • CYLINDER VOLUME: 3 L.
  • SAFETY VALVE: Set 195 +15/-23 bar
  • CYLINDER MATERIAL: Alluminium alloy AA6061
  • EXTERNAL/INTERNAL TREATMENT: Sandblast and epoxypolyestere poweder painting, Red Ral 3000 colour
