10kg Co2 wheeled fire extinguisher, temperature range from -30°C to +60°C, model 14103-1 manufactured in accordance to EN 1866-1, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), model 17103-1 certified according to the directive for pressure equipment PED 2014/68/EU.
-Quality Product certification guaranteed by Bureau Veritas Italia.
-Suitable for use on fire involving electrical voltages up to 1000 V, at a distance of 1 mt.
Â
Characteristics:
- Cyliner:Â Nr. 2 cylinders 5kg alloy steel,epoxypolyestere powder painting,Red Ral 3000.
- Extinguishing Agent:Â Carbon Dioxide 99,99%.
- Valve:Â M. 25x2, brass body, red painting Ral 3000, with protection for valve.
- Use: B fire rating (flammable liquids)
- Bracket:Â Chassis on wheels, red painting Ral 3000.
- Fire Rating: 144Â B
- Extinguishing Agent: Co2 99,99%
- Temperature Range: -30°C +60°C
- Nominal Charge: 10Â Kg
- Full Weight: ~ 36Â kg
- Dimensions Height 940 mm Width 430 mm Depth 480 mm
- Discharge Time: 16Â sec.
- Valve Tightening Torque:Â Minimum 95 Nm, Maximum 130 Nm
- Cylinder Pressure Test: PT 250 Bar
- Cylinder Volume: 7,5Â L. x 2
- Safety Valve: Set 195 +/- 10 bar
- Cylinder Material:Â Alloy steel
- External/Internal Treatment:Â Sandblast and epoxypolyestere poweder painting, Red Ral 3000 colour
