Foam Anti-freeze Portable fire extinguisher L 6 En 3-7 - Model: 22064-11

Foam Anti-freeze Portable fire extinguisher L 6 - 43A 233B 75F - EN 3-7 - Model: 22064-11 - Dolomiti 6 Super

Foam Anti-freeze Portable fire extinguisher L 6 - 43A 233B 75F - EN 3-7 - Model: 22064-11 - Dolomiti 6 Super


Foam portable fire extinguisher L 6 - 22064-11 - PED 2014/68/UE


Approved / Certified:


Fire Rating: 43 A 233 B 75 F


- 6 L foam fire extinguisher, temperature range from -10°C to +60°C, manufactured in accordance to EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU.

- Quality Product certification guaranteed by Bureau Veritas Italia.

- Suitable for use on fire involving voltages of up to 1000 volts.


Features:

- Cylinder: Deep drawing alloy steel, with clip, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: EW-10 foam.
- Propellant: Dehumidified air or N2.
- Valve: CPF brass M 30X1.5, levers with green/white painting.

- Use: A B F fire rating (solid materials, flammable liquids, coocking oil).
- Bracket: Wall-mounted in standard equipment.
Clip detail:


Technical Specifications:

- Fire Rating: 43 A 233 B 75 F
- Extinguishing Agent: EW-10 foam

- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: -10°C +60°C
- Nominal Charge: 6 L
- Full Weight: ~ 9,4 Kg
- Dimensions: Height  560 mm, Diameter 160 mm
- Discharge Time: 24 sec.
- Max Valve Tightening: Between 40 and 50 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 7,8 L.
- Safety Valve: Set 20 and 26 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour / Plastified
